1. Power System
Motor Type: Intermediate Brushless DC Motor (Mid-drive)
Rated Power: 3000 W
Peak Power: 10000 W
Max Torque (Rear Wheel): 385.65 N·m (with 58T Sprocket)
Controller: 72V 100A Sine Wave Controller
2. Battery & Charging
Battery Type: Samsung 21700 Lithium Cells
Capacity: 72V 40Ah (2.88 KWh)
Battery Lifecycle: ≥ 20,000 times
Charger: 10A Smart Charger
Charging Time: Approximately 4 hours
3. Performance
Max Speed: ≥ 85 km/h
Range: 120 km
Max Climbing Angle: ≥ 65°
Rated Loading Capacity: 100 kg
Max Loading Capacity: 200 kg
4. Chassis & Components
Frame: 6061 Forged Aluminum Alloy
Surface Treatment: Anodic Oxidation
Front Suspension: DNM hydraulic inverted telescopic shock, damping adjustable, 200mm travel
Rear Suspension: DNM hydraulic spring compound shock, preload/damping adjustable, 85mm travel
Braking System: Front & Rear 203mm ventilated discs with hydraulic 4-piston calipers
Tires: Front 70/100-19; Rear 80/100-19
Display: YXT One-Line Communication display with USB PORT
Headlight: Oversized High-intensity LED
5. Dimensions & Weight
Vehicle Dimensions: 1880mm × 770mm × 1088mm
Wheelbase: 1285mm
Seat Height: 860mm
Min. Ground Clearance: 300mm
Curb Weight: 65 kg
Gross Weight (G.W.): 84 kg
6. Logistics & Others
Packing Size: 168cm × 35cm × 83cm
Packaging: Wood frame + 7-layer corrugated carton
Container Loading: 126 units per 40′ HQ
Lead Time: 45 days
